3mil High Density HDI PCB Board 14 Layer Anti Oxidation Waterproof

Certification
China Quanhong FASTPCB certification
China Quanhong FASTPCB certification
I'm Online Chat Now

3mil High Density HDI PCB Board 14 Layer Anti Oxidation Waterproof

3mil High Density HDI PCB Board 14 Layer Anti Oxidation Waterproof
3mil High Density HDI PCB Board 14 Layer Anti Oxidation Waterproof

Large Image :  3mil High Density HDI PCB Board 14 Layer Anti Oxidation Waterproof

Product Details:
Brand Name: FASTPCB
Payment & Shipping Terms:
Minimum Order Quantity: 10PCS
Price: USD 0.01-100PCS
Packaging Details: Inner: vacuum packing or Anti-static package, Outer: export carton
Payment Terms: L/C, T/T
Supply Ability: 25,000 ㎡ / month Or 10PCS/48Hour(Double-Sided Printed Board)Or 10PCS/72Hour(Multilayer printed circuit board )

3mil High Density HDI PCB Board 14 Layer Anti Oxidation Waterproof

Description
Name: HDI Pcb Board Base Material: M6
Number Of Layers: 14Layer Board Thickness: 1.2mm+/-10%
Min. Line Width: 0.1mm Inner Layer Spacing: 0.17mm
High Light:

3mil HDI PCB Board

,

14L HDI PCB Board

,

3mil hdi circuit boards

3mil High Density HDI PCB Board 14 Layer Anti Oxidation Waterproof



High Density Interconnector HDI Pcb Board Electronics 14 Layer Anti oxidation



14 Layer M6 Material Circuit Board

The 14 layer M6 material circuit board is one of the HDI PCB boards developed and produced by Shenzhen Quanhong Electronics Co., Ltd. It is made of Shengyi s1000-2m material and surface gold deposition process. The products are widely used in 5g and other communication products.


1, Craftsmanship
Use high-quality plates,smooth cutting. stable color,good brightness and Smooth coating
2, Anti-oxidation, high temperature resistance, waterproof
Anti-oxidation surface finish to ensure heat-shock resistance, moisture protec-tion to protect the surface from rusting and oxidation.
3, Advantages of PCB Boards:
Extremely effective treatment of thermal diffusion in the circuit design scheme, thereby reducing module operating temperature,extending service life, and improving power density and reliability.



Rigid PCB Manufacturing Capability

Rigid PCB Manufacturing Capability
ItemPCBHDI
Layer1-401-40
Minimum linewidth/linespacing3MIL/3MIL(0.075mm)2MIL/2MIL(0.05MM)
Minimum hole diameter6MIL(0.15MM)6MIL(0.15MM)
Minimum solder resist opening (single-side)1.5MIL(0.0375MM)1.2MIL(0.03MM)
Minimum solder resist bridge3MIL(0.075MM)2.2MIL(0.055MM)
Maximum aspect Ratio (thickness/hole diameter)10:018:01
Impedance control accuracy+/-8%+/-8%
Finished thickness0.3-3.2MM0.2-3.2MM
Maximum board size630MM*620MM620MM*544MM
Maximum finished copper thickness6OZ(210UM)2OZ(70UM)
Minimum board thickness6MIL(0.15MM)3MIL(0.076MM)
Maximum layer14层12层
Surface treatmentHASL-LF,OSP ,Immersion Gold, Immersion Tin ,Immersion AgImmersion Gold,OSP,selectiveimmersion gold,
carbon print
Min/max laser hole size/3MIL / 9.8MIL
Laser hole size tolerance/10%



Packaging & Delivery
Packaging Details:Inner: vacuum packing or Anti-static package,
Outer: export carton
or according to the customer's requirement.
Port:Shenzhen or Hongkong
Lead Time:Quantity(Pieces)1-1011-100101-1000>1000
 Est. Time(days)202125To be negotiated



FAQ:

Q: What service do you have?
FASTPCB: We provide turnkey solution including PCB fabrication, SMT, plastic injection & metal,final assembly, testing and other value-added service.



Q: What is needed for PCB & PCBA quotation?
FASTPCB: For PCB: Quantity, Gerber file and technic requirements(material,size, surface finish treatment, copper thickness,board thickness).
For PCB: PCB information, BOM,Testing documents.



Q: How to keep our product information and design file secret ?
FASTPCB: We are willing to sign a NDA effect by customers side local law and promising tokeep customers data in high confidential level.



Q: What are the main products of your PCB/PCBA services?
FASTPCB: Automotive, Medical, Industry Control, IOT, Smart Home, Military, Aerospace.



Q: What is your minimum order quantity (MOQ)?
FASTPCB: Our MOQ is 1 PCS, sample and mass production all can support.



Q: Are you factory?
