Round 1oz Copper PCB Board Black Green Oil Drilling Printed Circuit Board
  • Round 1oz Copper PCB Board Black Green Oil Drilling Printed Circuit Board
  • Round 1oz Copper PCB Board Black Green Oil Drilling Printed Circuit Board

Round 1oz Copper PCB Board Black Green Oil Drilling Printed Circuit Board

Place of Origin China
Brand Name HF
Certification ISO CE
Model Number PCB
Product Details
Base Material:
FR4 ,Rogers , Aluminum ,Hight TG
Number Of Plies:
1 Layer
Board Thickness:
1.4mm
Copper Thickness:
1oz
Solder Color:
Green,blue
Silkscreen Color:
White
Surface Finishing:
Osp
Material:
FR4 ,Rogers , Aluminum ,High TG,CEM1, CEM3, Halogen Free
Layer Coun:
1-40
Solder Mask Color:
Green, Yellow,white, Blue,black,red
Service:
OEM/ODM/PCB/Components Sourcing/Assembly/Programming/Testing...One-stop Turnkey Service.
Test:
100% AOI, X-ray, Flying Probe Test.
High Light:

Round 2oz copper pcb

,

Printed 2oz copper pcb

,

2oz copper pcb board

Payment & Shipping Terms
Minimum Order Quantity
5PCS
Price
Negotiable
Packaging Details
High quality carton packing, high quality vacuum packing,
Delivery Time
5~8 days
Payment Terms
L/C, T/T,PAYPAL
Supply Ability
Ten thousand square meters per month
Product Description

Round 1oz PCB Black Oil Green Oil Drilling Printed Circuit Board



Capability


1 High precision prototype PCB bulk production

2

1-28 layers 1 layers
3 3mil 6mil
4 0.15mm 0.15mm
5 Aspect Ration≤13:1 Aspect Ration≤13:1
6 2 layers:0.2mm;4 layers:0.35mm;6 layers:0.55mm;8 layers:0.7mm;10 layers:0.9mm 1 layers
7 Immersion Gold:Au,1—8u”
Gold finger:Au,1—150u”
Gold Plated:Au,1—150u”
Nickel Plated :50—500u”
Gold Plated:Au,1—150u”
8 Board thickness≤1.0mm:+/-0.1mm
1.0mm<Board thickness≤2.0mm:+/-10%
Board thickness>2.0mm:+/-8%
1.0mm<Board thickness≤2.0mm:+/-10%
9 ≤100mm:+/-0.1mm
100< ≤300mm:+/-0.15mm
>300mm:+/-0.2mm
≤100mm:+/-0.1mm
10 ±10% ±10%





Round 1oz Copper PCB Board Black Green Oil Drilling Printed Circuit Board 0Round 1oz Copper PCB Board Black Green Oil Drilling Printed Circuit Board 1Round 1oz Copper PCB Board Black Green Oil Drilling Printed Circuit Board 2



Round 1oz Copper PCB Board Black Green Oil Drilling Printed Circuit Board 3
Round 1oz Copper PCB Board Black Green Oil Drilling Printed Circuit Board 4

RFQ
1. Are you headquarter or branch?
We are Ping you headquarter and factory.

2. Can I ask for samples before placing an order?
Yes, we welcome sample order to test and check quality,Miced samles are acceptable.

3. How to be your overseas agent?
Depends which area you are located in,Every conuntries are different.

4. What need I do if I want to pint my own logo?
First, please send us your logo flie in high resolution, We will make some drafts for your reference to confirm the position and size of your logo.Next we will 1-2 samples for you to check the actual effect.Finally the formal production will start after the sample confrimed .

5. Can you ship the goods to my agent or shipping forwarder in China?
Yes,We can,please kindly contact with your agent in advance and us detailed address.
